Building Technologies Division User Manual LMS14... CC1U7471en
3 Mounting and installation 28.01.2015
3.4.3 List of terminals of LMS14… complete (Basic)
LMS14... standard (Basic)
Terminal Mating connector
marking Number
of pins
Supplier Type/coding
X1a 3 Wieland 25.320.3353.0 green
X1c 4 Lumberg 3636 04K02
X1d 5 Lumberg 3636 05K02
X1e 2 Lumberg 3636 02K10
X2a 5 Lumberg 3636 05K22
X4a 8 Lumberg 3515 08K20
X5b 12 Lumberg 3636 12K01
X6b 8 Lumberg 3636 08K10
X7b 6 Lumberg 3636 06K09
X8a 4 Lumberg 3515 04K06
X10b 4 Lumberg
3515 04K26
X11 14 Lumberg 302299 14 uncoded
X12 4 Molex 48037-2200 uncoded
X13 6/4 Uncoded
X15a 2 Lumberg 3516 02K05
X16a 5 Lumberg 3515 05K25
X17 1 Uncoded
X18a 2 Lumberg 3636 02K05
X30 9 Lumberg 3515 09K15
X50 5 Lumberg 3515 05K23
X60 2x3 Uncoded
Key to LMS14… complete (Basic)
AUX... Auxiliary output
B2 Boiler sensor
B3 DHW sensor
B7 Boiler return sensor
B9 Outside sensor
B38 DHW outlet sensor
BX... Sensor input
H... Function input
P1 PWM output
QX... Relay output
STB Safety limit thermostat (SLT)
UX... PWM output / 10 output
WX1 Stepper motor output
Note!
The connector designations only specify coding and type. When ordering, also
consider the requirements placed on the material (e.g. filament test) and design.
