Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
6.18.15 Excess heat draw
Line no. Operating line
5085 Excess heat draw
Off
On
Excess heat draw can be triggered by the following functions:
- Inputs Hx
- Solid fuel boiler with excess heat draw
When excess heat draw is activated, surplus heat can be fed to the DHW storage tank.
Off
Function is deactivated.
On
Function is activated.
6.18.16 Plant hydraulics
Line no. Operating line
5090 With buffer
No
Yes
If a buffer storage tank is installed, select whether the DHW storage tank can draw heat
from it. When using alternative heat sources, the buffer storage tank temperature is
used as a control criterion for the release of additional heat sources.
No
Hydraulically speaking, the DHW storage tank is not connected to the buffer storage
tank.
Yes
The DHW storage tank is hydraulically connected to the buffer storage tank. This
means that the transfer of heat via Q3 is always possible.
Line no. Operating line
5092 With prim contr/system pump
No
Yes
Enter whether the DHW storage tank receives its heat via the primary controller or with
the help of the system pump (depending on the type of plant).
Line no. Operating line
5093 With solar integration
No
Yes
Enter whether the DHW storage tank receives its heat from the solar collectors.
Excess heat draw
With buffer
With prim contr/system
pump
With solar integration
