6 The settings in detail
28.01.2015
Line no.
Operating line
UX2 UX3
7717 7725
Output signal
UXx
None
Closed (ooo),
Open (---)
Pulse
Frequency
Hz
Voltage
V
PWM
%
Line no.
Operating line
UX2 UX3
7719 7726
PWM output UXx
Current PWM output/voltage output displayed at the UX2 output/UX3 ou
tput.
Output signal UXx
PWM output UXx
506
