Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
Note!
Depending on Release QAA fan param [4337.1], the required fan speeds to be
applied differ:
If Release QAA fan param [4337.1] is set to On, the Required speed LF (9524) or
Required speed HF (9529) applies to low-fire; if set to Off, the Required speed LF
min (9525) or Required speed HF max (9530) applies to high-fire.
If a modulating pump is used, the parameterized maximum pump control ensures DHW
charging:
Degree of modulation of pump = Pump speed max (5102)
At the end of the DHW request, the pump starts to overrun. The overrun time can be
set via Pump overr time after DHW (2253).
Line no. Operating line
8311
Boiler setpoint
8830
DHW temp 1
8831
DHW temp setpoint
8832
DHW temp 2
Line no. Operating line
1645
Legionella funct setpoint
2253
Pump overr time after DHW
2460
Switching diff on DHW
2461
Switching diff off min DHW
2462
Switching diff off max DHW
5022
Type of charging
5024
Switching diff
5102
Pump speed max
9524
Required speed LF
9525
Required speed LF min
9529
Required speed HF
9530
Required speed HF max
Info/diagnostics
A
dditional parameter
s
