350/617
Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
If, during charging, the temperature at sensor B36 (DHW charging temp (8836))
exceeds the charging setpoint by the current Switching diff off min DHW
(2461)/Switching diff off max DHW (2462), the burner is switched off. It is switched on
again as soon as the temperature at sensor B36 drops by the parameterized Switching
diff on DHW (2460) below the charging temperature setpoint. The setting range for the
switch-on differential starts at 0 °C.
The output request to the burner is controlled between the parameterized Required
speed LF min (9525) and the maximum output for Fan speed full charging max (2442).
If, during the time full charging is active, the enable criterion for full charging does not
apply anymore, the DHW request is ended according to the criteria for recharging.
Line no. Operating line
8830
DHW temp 1
8831
DHW temp setpoint
8832
DHW temp 2
8836
DHW charging temp
Line no. Operating line
2442
Fan speed full charging max
2460
Switching diff on DHW
2461
Switching diff off min DHW
2462
Switching diff off max DHW
5024
Switching diff
5101
Pump speed min
5140
Intermediate circuit boost
5141
Excess interm circ temp max
5146
Full charging with B36
9525
Required speed LF min
Info/diagnostics
