Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
Line no. Function 1
(No DHW)
2
(DHW storage
tank)
3
(Instantaneous
water heater)
4
(DHW
stratification
storage tank)
5891 Relay output QX2 None None None DHW intermediate
circuit pump Q33
5892 Relay output QX3 None DHW controlling
element Q3
Instantaneous water
heater controlling
element Q34
DHW controlling
element Q3
5894 Relay output QX4 None None None None
5930 Sensor input BX1 None Sensor B31 None Sensor B31
5931 Sensor input BX2 None None None Sensor B36
5932 Sensor input BX3 None None None None
5950 Function input H1 None None DHW flow switch None
5960 Function input H3 None None None None
5970 Function input H4 None None None None
5977 Function input H5 Room thermostat
HC1
Room thermostat
HC1
Room thermostat
HC1
Room thermostat
HC1
6008 Function input H6 None None None None
6011 Function input H7 None None None None
6020 Function extension module 1 None None None Multifunctional
6021 Function extension module 2 None None None None
6022 Function extension module 3 None None None None
6030 Relay output QX21 module 1 None None None Collector pump Q5
6031 Relay output QX22 module 1 None None None None
6032 Relay output QX23 module 1 None None None None
6033 Relay output QX21 module 2 None None None None
6034 Relay output QX22 module 2 None None None None
6035 Relay output QX23 module 2 None None None None
6036 Relay output QX21 module 3 None None None None
6037 Relay output QX22 module 3 None None None None
6038 Relay output QX23 module 3 None None None None
6040 Sensor input BX21 module 1 None None None Sensor B6
6041 Sensor input BX22 module 1 None None None None
6042 Sensor input BX21 module 2 None None None None
6043 Sensor input BX22 module 2 None None None None
6044 Sensor input BX21 module 3 None None None None
6045 Sensor input BX22 module 3 None None None None
6046 Function input H2 module 1 None None None None
6054 Function input H2 module 2 None None None None
6062 Function input H2 module 3 None None None None
6085 Function output P1 None None None None
6600 Device address 1 1 1 1
6601 Segment address 0 0 0 0
With operator terminals having a double display, the display also shows whether the
preselection is still the same or whether it has already been adapted (that is, if at least
one parameter has been changed).
When using operator terminals without double display, it may be necessary to switch to
the next parameter to see the required display.
Changed
At least one parameter of the preselection has been changed.
Unchanged
Parameters of the preselection have not yet been changed.
