Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
Function H1 H3 H4 H5 H6 H7
0 None
1 Optg mode changeover HCs+DHW
2 Optg mode changeover DHW
3 Optg mode changeover HCs
4 Optg mode changeover HC1
5 Optg mode changeover HC2
6 Optg mode changeover HC3
7 Heat generation lock
8 Error/alarm message
9 Consumer request VK1
10 Consumer request VK2
11 Release swi'pool consumer
12 Excess heat discharge
13 Release swi pool solar
14 Operating level DHW
15 Operating level HC1
16 Operating level HC2
17 Operating level HC3
18 Room thermostat HC1
19 Room thermostat HC2
20 Room thermostat HC3
21 DHW flow switch
22 DHW thermostat
24 Pulse count
28 Checkback signal flue gas damper
29 Start prevention
31 Boiler flow switch
32 Boiler pressure switch
34 Gas pressure switch
50 Flow measurement Hz
51 Consumer request VK1 10V
52 Consumer request VK2 10V
54 Pressure measurement 10V
58 Output request 10V
Assignment of line numbers to the individual parameters of inputs Hx:
Function Type U1 F1 U2 F2
H1 5950 5951 5953 5954 5955 5956
H3 5960 5961 5963 5964 5965 5966
H4 ¹) 5970 5971 5973 5974 5975 5976
H5 5977 5978 --- --- --- ---
H6 6008 6009 --- --- --- ---
H7 6011 6012 --- --- --- ---
¹) At H4, a frequency value is to be entered for U1 and U2 – not a voltage value
