Siemens LMS14

412/617
Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
Line no. Operating line
5951
5961
5971
5978
6009
6012
Contact type Hx
NC
NO
The type of contact of Hx can be selected (NO or NC).
Parameters
Type of contact Hx
Contact state at
terminal Hx
Functional state/impact
Normally open contact (NO) Open Not active
Closed Active
Normally closed contact (NC) Open Active
Closed Not active
NC
The contact is normally closed and must open to activate the selected function.
NO
The contact is normally open and must close to activate the selected function.
Line no. Operating line
5953 Voltage value 1 H1
Line no. Operating line
5954 Function value 1 H1
Line no. Operating line
5955 Voltage value 2 H1
Line no. Operating line
5956 Function value 2 H1
Line no. Operating line
5963 Voltage value 1 H3
Line no. Operating line
5964 Function value 1 H3
Line no. Operating line
5965 Voltage value 2 H3
Line no. Operating line
5966 Function value 2 H3
Line no. Operating line
5973 Frequency value 1 H4
Line no. Operating line
5974 Function value 1 H4
Line no. Operating line
5975 Frequency value 2 H4
Contact type H1, H3,
H4, H5, H6, H7
Voltage value 1 H1
Function value 1 H1
Voltage value 2 H1
Function value 2 H1
Voltage value 1 H3
Function value 1 H3
Voltage value 2 H3
Function value 2 H3
Frequency value 1 H4
Function value 1 H4
Frequency value 2 H4
