Siemens LMS14 User Manual

43/617
Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value Min Max Unit
Operator unit ACS420 ACS700/ACS790
Missing ¦ In operation ¦ No recept'n ¦ Change batt Not available ¦ Ready to operate ¦ No
reception ¦ Change battery
Not available ¦ Ready to operate ¦ No
reception ¦ Change battery
137 Operator unit 3
Missing ¦ In operation ¦ No recept'n ¦ Change batt
Operator unit 3
Not available ¦ Ready to operate ¦ No
reception ¦ Change battery
Operator unit 3
Not available ¦ Ready to operate ¦ No
reception ¦ Change battery
- -
138 Service unit
Missing ¦ In operation ¦ No recept'n ¦ Change batt
Service Unit
Not available ¦ Ready to operate ¦ No
reception ¦ Change battery
Service unit
Not available ¦ Ready to operate ¦ No
reception ¦ Change battery
- -
140 Delete all devices
No ¦ Yes
Delete all Devices
No ¦ Yes
Delete all devices
No ¦ Yes
No -
Time prog heating circuit 1
500 Preselection
Mo - Su ¦ Mo – Fr ¦ Sa - Su ¦ Mo ¦ Tu ¦ We ¦ Th ¦ Fr ¦
Sa ¦ Su
Switch prg HC1 Mo
Mo - Su ¦ Mo – Fr ¦ Sa - Su ¦ Mo ¦ Tu ¦ We ¦
Th ¦ Fr ¦ Sa ¦ Su
Time switch program HC1 Monday
Mo - Su ¦ Mo – Fr ¦ Sa - Su ¦ Mo ¦ Tu ¦ We ¦
Th ¦ Fr ¦ Sa ¦ Su
Mo - So -
501 1st phase on Switch prg HC1 Tu Time switch program HC1 Tuesday 6:00 00:00 24:00 hh:mm
502 1st phase off Switch prg HC1 We Time switch program HC1
Wednesday
22:00 00:00 24:00 hh:mm
503 2nd phase on Switch prg HC1 Th Time switch program HC1 Thursday 24:00 00:00 24:00 hh:mm
504 2nd phase off Switch prg HC1 Fr Time switch program HC1 Friday 24:00 00:00 24:00 hh:mm
505 3rd phase on Switch prg HC1 Sa Time switch program HC1 Saturday 24:00 00:00 24:00 hh:mm
506 3rd phase off Switch prg HC1 Su Time switch program HC1 Sunday 24:00 00:00 24:00 hh:mm
516 Default values
No ¦ Yes
Standard TSP HC1
No ¦ Yes
Standard values TSP heating circuit
1
No ¦ Yes
No -
Time prog heating circuit 2
520 Preselection
Mo - Su ¦ Mo - Fr ¦ Sa - Su ¦ Mo ¦ Tu ¦We ¦ Th ¦ Fr ¦
Sa ¦ Su
Switch prg HC2 Mo
Mo - Su ¦ Mo – Fr ¦ Sa - Su ¦ Mo ¦ Tu ¦ We ¦
Th ¦ Fr ¦ Sa ¦ Su
Time switch program HC2 Monday
Mo - Su ¦ Mo – Fr ¦ Sa - Su ¦ Mo ¦ Tu ¦ We ¦
Th ¦ Fr ¦ Sa ¦ Su
Mo - So -
521 1st phase on Switch prg HC2 Tu Time switch program HC2 Tuesday 6:00 00:00 24:00 hh:mm
522 1st phase off Switch prg HC2 We Time switch program HC2
Wednesday
22:00 00:00 24:00 hh:mm
523 2nd phase on Switch prg HC2 Th Time switch program HC2 Thursday 24:00 00:00 24:00 hh:mm
524 2nd phase off Switch prg HC2 Fr Time switch program HC2 Friday 24:00 00:00 24:00 hh:mm
525 3rd phase on Switch prg HC2 Sa Time switch program HC2 Saturday 24:00 00:00 24:00 hh:mm
526 3rd phase off Switch prg HC2 Su Time switch program HC2 Sunday 24:00 00:00 24:00 hh:mm
