Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
Line no. Operating line
6142 Water pressure critical min
Line no. Operating line
6152 Water press 2 critical min
Line no. Operating line
6182 Water press 3 critical min
If the pressure acquired via input H1, H2 (EM1...EM3) or H3 drops below the limit value
set here, the respective error message is delivered and the burner is immediately shut
down.
118: Water pressure too low
177: Water pressure 2 too low
323: Water pressure 3 too low
Line no. Operating line
6143 Water Pressure SD
Line no. Operating line
6153 Water Pressure 2 SD
Line no. Operating line
6183 Water Pressure 3 SD
When the water pressure drops, falling below the limit value by the switching
differential, the error message is canceled.
If the water pressure rises, exceeding the limit value by the switching differential, the
error message is canceled.
If the water pressure rises, exceeding the limit value by the switching differential, the
error message is canceled.
Note!
If, with 2 or 3 extension modules, water pressure supervision at H2 is activated, all
inputs H2 use the same parameter values. The error message with the highest
priority is displayed.
The water pressure is displayed in the Info menu.
This is the value of the first input within the following sequence with a pressure
measurement assigned to it: H1, H2 EM1, H2 EM2, H2 EM3, H3.
Line no. Operating line
Water pressure
Line no. Operating line
9005 Water pressure H1
9006 Water pressure H2
9007 Water pressure H3
Water pressure
critical min
Water press 2 critical min
Water press 3 critical min
Water Pressure SD
Water Pressure 2 SD
Water Pressure 3 SD
Water pressure max
Water pressure min
Water pressure critical
min
