Siemens LMS14 User Manual

45/617
Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value Min Max Unit
Operator unit ACS420 ACS700/ACS790
605 3rd phase on TSP 5 Sat Time switch program 5 Saturday 24:00 00:00 24:00 hh:mm
606 3rd phase off TSP 5 Sun Time switch program 5 Sunday 24:00 00:00 24:00 hh:mm
616 Default values
No ¦ Yes
Standard TSP 5
No ¦ Yes
Standard values TSP 5
No ¦ Yes
No -
Holidays heating circuit 1
641 Preselection
Period 1 ¦ Period 2 ¦ Period 3¦ Period 4¦ Period 5¦
Period 6¦ Period 7¦ Period 8
Period 1 -
642 Start Holidays1HC1firstd Holiday period 1 HC1: first day --.-- 01.01 31.12 tt.MM
643 End Holidays1HC1lastd Holiday period 1 HC1: last day --.-- 01.01 31.12 tt.MM
648 Operating level
Frost protection ¦ Reduced
HolidayOptgLevel HC1
Frost ¦ Reduced
Holiday operating level HC1
Frost ¦ Reduced
Frost protection -
Holidays heating circuit 2
651 Preselection
Period 1 ¦ Period 2 ¦ Period 3¦ Period 4¦ Period 5¦
Period 6¦ Period 7¦ Period 8
Period 1 -
652 Start Holidays1HC2firstd Holiday period 1 HC2: first day --.-- 01.01 31.12 tt.MM
653 End Holidays1HC2lastd Holiday period 1 HC2: last day --.-- 01.01 31.12 tt.MM
658 Operating level
Frost protection ¦ Reduced
RoomTemp ComfSetp HC1
Frost ¦ Reduced
Holiday operating level HC2
Frost ¦ Reduced
Frost protection -
Holidays heating circuit 3
661 Preselection
Period 1 ¦ Period 2 ¦ Period 3¦ Period 4¦ Period 5¦
Period 6¦ Period 7¦ Period 8
Period 1 -
662 Start Holiday1HC3/PFirstDay Holiday period 1 HC3/P: First day --.-- 01.01 31.12 tt.MM
663 End Holiday1HC3/PLastDay Holiday period 1 HC3/P: Last day --.-- 01.01 31.12 tt.MM
668 Operating level
Frost protection ¦ Reduced
HolidayOptgLevelHC3/P
Frost ¦ Reduced
Holiday operating level HC3/P
Frost ¦ Reduced
Frost protection -
Heating circuit 1
700 Operating mode HC1
Protection ¦ Automatic ¦ Reduced ¦ Comfort
Operating mode heat circuit 1
Protection ¦ Automatic ¦ Reduced ¦ Comfort
Automatic -
710 Comfort setpoint RoomTemp ComfSetp HC1 Room temperature Comfort setpoint
HC1
20.0 BZ 712 BZ 716 °C
712 Reduced setpoint RmTmp RedSetp HC1 Room temp reduced setpoint heat
circuit 1
16 BZ 714 BZ 710 °C
