Siemens LMS14

465/617
Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
Line no. Operating line
6213 Check no. heat source 2
Solid fuel boiler
0 No solid fuel boiler
1 Solid fuel boiler, boiler pump
2 Solid fuel boiler, boiler pump,
integration DHW storage tank
Line no. Operating line
6215 Check no. storage tank
Buffer storage tank DHW storage tank
0 No buffer storage tank 0 No DHW storage tank
1 Buffer storage tank 1 Electric immersion heater
2 Buffer storage tank, 2 Solar connection
solar connection 4 Charging pump
4 Buffer storage tank, 5 Charging pump,
heat source valve solar connection
5 Buffer storage tank, 13 Diverting valve
solar connection, 14 Diverting valve,
heat source valve solar connection
16 Primary controller, without
heat exchanger
17 Primary controller,
1 heat exchanger
19 Intermediate circuit,
without heat exchanger
20 Intermediate circuit,
1 heat exchanger
22 Charging pump/
intermediate circuit,
without heat exchanger
23 Charging pump/
intermediate circuit,
1 heat exchanger
25 Diverting valve/
intermediate circuit,
without heat exchanger
26 Diverting valve/
intermediate circuit,
1 heat exchanger
Check no. heat source 2
Check no. storage tank
