Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value
Min
Max
Unit
Operator unit ACS420 ACS700/ACS790
791 Optimum stop control max OptStopCtrl MaxTime1 Optimum stop control max forward
shift HC1
0 0 360 Min.
794 Heat up gradient Heat up gradient Heat up gradient 60 0 600 min/k
800 Reduced setp increase start StartRedRTSetpIncrHC1 Start reduced room temp setpoint
increase HC1
/BZ 801 10 °C
801 Reduced setp increase end EndRedRTSetpIncrHC1 End reduced room temp setpoint
increase HC1
-15 -30 BZ 800 °C
809 Continuous pump operation
No ¦ Yes
Continuous PumpOp HC1
No ¦ Yes
Continuous pump operation HC1
No ¦ Yes
No
812 Frost protection flow temp
Off ¦ On
FrostProtFlowTemp HC1
Off ¦ On
Frost protection flow temp HC1
Off ¦ On
On -
820 Overtemp prot pump circuit
Off ¦ On
OvertempProt HC1
Off ¦ On
Pump heating circuit overtemp
protection HC1
Off ¦ On
On
-
830 Mixing valve boost MixValveSetpBoost HC1 Mixing valve setpoint boost heating
circuit 1
5 0 50 °C
832 Actuator type
2-positioin ¦ 3-position
Actuator CtrlMod HC1
Two-positioin ¦ Three-position
Actuator control mode heat circuit 1
Two-positioin ¦ Three-position
Three-position -
833 Switching differential 2-pos ActuatorSwiDiff HC1 Actuator switching differential heat
circuit 1
2 0 20 °C
834 Actuator running time Actuator RunTime HC1 Actuator running time heat circuit 1 120 30 873 s
835 Mixing valve Xp Xp heating circuit 1 P-band (Xp) heat circuit 1 32 1 100 °C
836 Mixing valve Tn Tn heating circuit 1 Integral action time (Tn) heat circuit
1
120 10 873 s
850 Floor curing function
Off ¦ Functional heating ¦ Curing heating ¦
Functional/curing heating ¦ Curing/functional
heating ¦ Manually
FloorPlastrDryUpFnct1
Off ¦ Functional heating ¦ Curing heating ¦
Functional and curing heating ¦ Curing and
functional heating ¦ Manually
Flooring plaster dry up function HC1
Off ¦ Functional heating ¦ 'Belegreif'
heating ¦ Functional + 'Belegreif' heating ¦
Belegreif' + functional heating ¦ Manuell
Off -
851 Floor curing setp manually FloorSetp man HC1 Floor setpoint manually HC1 25 0 95 °C
855 Floor curing setp current FlowTmpSetFloorPlast1 Flow temp setpoint flooring plaster
dry up HC1
0 95 °C
856 Floor curing day current FloorPlastrDryUpDay 1 Flooring plaster dry up day HC1 0 32
861 Excess heat draw
Off ¦ Heating mode ¦ Always
Overtemp drop HC1
Off ¦ Heating mode ¦ Always
Overtemperature drop heating
circuit 1
Off ¦ Heating mode ¦ Always
Always
