Siemens LMS14 User Manual

512/617
Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
Line no. Operating line
8005 State boiler
SLT has tripped
...
Enduser (info level) Commissioning, heating engineer State number
Safety limit thermostat limits
output
245
SLT has cut out SLT has cut out 1
SLT test active SLT test active 123
Fault Fault 2
Flue gas temperature, shutdown 232
Flue gas temperature, load limitation 233
Flue gas temperature to high 234
Limit thermostat has cut out Limit thermostat has cut out 3
Manual control active Manual control active 4
Low flow rate Low flow rate 253
Controller stop active Controller stop active 220
Chimney sweep function, high-fire 5
Chimney sweep function, low-fire 6
Chimney sweep function active 7
Locked, manually 8
Locked, solid fuel boiler 172
Locked, automatically 9
Locked, outside temperature 176
Locked, Economy mode 198
Locked 10
Minimum limitation 20
Minimum limitation, low-fire 21
Minimum limitation active Minimum limitation active 22
Protective startup 11
Protective startup, low-fire 12
Return limitation 13
Return temperature limitation, low-fire 14
In operation 18
Charging buffer storage tank Charging buffer storage tank 59
In operation for HC, DHW In operation for HC, DHW 170
In low-fire operation for HC, DHW In low-fire operation for HC, DHW 171
Released for HC, DHW Released for HC, DHW 173
In operation for DHW In operation for DHW 168
In low-fire operation for DHW In low-fire operation for DHW 169
Released for DHW Released for DHW 174
In operation for heating circuit In operation for heating circuit 166
In low-fire operation for HC In low-fire operation for HC 167
Released for HC Released for HC 175
Overrun active Overrun active 17
Released Released 19
Frost protection plant active 23
Frost protection active 24
Off Off 25
