Building Technologies Division User Manual LMS14… CC1U7471en
6 The settings in detail 28.01.2015
Line no. Operating line
9612 GP configuration
GP not connected
GP connected
Configuration of input for gas pressure switch:
GP not connected
No monitoring by gas pressure switch (input can be used for some other function).
GP connected
Monitoring by gas pressure switch (see sequence diagram).
Warning!
Here, the safety-related setting for input H6 is made. Parameter Function input
H6 (6008) is of importance only when set to GP not connected.
If, with this safety-related parameter, function GP connected is selected,
parameter Function input H6 (6008) only accepts None.
Line no. Operating line
9613 Home run mode
Start with HomeRun
Start without HomeRun
Selection of Postpurging mode.
Startup with HomeRun
At the end of postpurging TN2, the change to home run is always made.
Startup without HomeRun
Direct startup from postpurging TN2 possible (interruptable postpurging).
Line no. Operating line
9614 Postpurging level
Run
Prepurge
Selection of postpurging level at the end of the operating phase.
Run
Postpurging based on last operational control.
Prepurge
Postpurging at prepurge speed.
GP configuration
Home run mode
Postpurging level
