Siemens LMS14 - Page 89

89/617
Building Technologies Division User Manual LMS14... CC1U7471en
5 Handling 28.01.2015
Line no.
Operating line
Default value Min Max Unit
Operator unit ACS420 ACS700/ACS790
¦ Status output K35 ¦ Status information K36 ¦ Fan
shutdown K38 ¦ dT controller 1 K21 ¦ dT controller
2 K22
Heat circuit pump HC1 Q2 ¦ Heat circuit
pump HC2 Q6 ¦ DHW ctrl elem Q3 ¦
Instant heater ctrl elem Q34 ¦ Water filling
K34 ¦ 2nd boiler pump speed Q27 ¦ Status
output K35 ¦ Status information K36 ¦ Fan
shutdown K38 ¦ dT controller 1 K21 ¦ dT
controller 2 K22
Heat circuit pump HC1 Q2 ¦ Heat circuit
pump HC2 Q6 ¦ DHW ctrl elem Q3 ¦
Instant heater ctrl elem Q34 ¦ Water filling
K34 ¦ 2nd boiler pump speed Q27 ¦ Status
output K35 ¦ Status information K36 ¦ Fan
shutdown K38 ¦ dT controller 1 K21 ¦ dT
controller 2 K22
6040 Sensor input BX21 module 1
None ¦ DHW sensor B31 ¦ Collector sensor B6 ¦
DHW circulation sensor B39 ¦ Buffer sensor B4 ¦
Buffer sensor B41 ¦ Flue gas temp sensor B8 ¦
Common flow sensor B10 ¦ Solid fuel boiler sensor
B22 ¦ DHW charging sensor B36 ¦ Buffer sensor
B42 ¦ Common return sensor B73 ¦ Cascade return
sensor B70 ¦ Swimming pool sensor B13 ¦ Solar
flow sensor B63 ¦ Solar return sensor B64 ¦ Primary
exch sensor B26
Sensor BX21 module 1
None ¦ DHW sensor B31 ¦ Collector sensor
B6 ¦ DHW circulation sensor B39 ¦ Buffer
sensor B4 ¦ Buffer sensor B41 ¦ Flue gas
temp sensor B8 ¦ Segment flow sensor
B10 ¦ Solid fuel boiler sensor B22 ¦ DHW
charging sensor B36 ¦ Buffer sensor B42 ¦
Segment return sensor B73 ¦ Cascade
return sensor B70 ¦ Pool sensor B13 ¦
Solar flow sensor B63 ¦ Solar return
sensor B64 ¦ Primary exch sensor B26
Sensor input BX21 module 1
None ¦ DHW sensor B31 ¦ Collector sensor
B6 ¦ DHW circulation sensor B39 ¦ Buffer
sensor B4 ¦ Buffer sensor B41 ¦ Flue gas
temp sensor B8 ¦ Segment flow sensor
B10 ¦ Solid fuel boiler sensor B22 ¦ DHW
charging sensor B36 ¦ Buffer sensor B42 ¦
Segment return sensor B73 ¦ Cascade
return sensor B70 ¦ Pool sensor B13 ¦
Solar flow sensor B63 ¦ Solar return
sensor B64 ¦ Primary exch sensor B26
None
6041 Sensor input BX22 module 1
None ¦ DHW sensor B31 ¦ Collector sensor B6 ¦
DHW circulation sensor B39 ¦ Buffer sensor B4 ¦
Buffer sensor B41 ¦ Flue gas temp sensor B8 ¦
Common flow sensor B10 ¦ Solid fuel boiler sensor
B22 ¦ DHW charging sensor B36 ¦ Buffer sensor
B42 ¦ Common return sensor B73 ¦ Cascade return
sensor B70 ¦ Swimming pool sensor B13 ¦ Solar
flow sensor B63 ¦ Solar return sensor B64 ¦ Primary
exch sensor B26
Sensor BX22 module 1
None ¦ DHW sensor B31 ¦ Collector sensor
B6 ¦ DHW circulation sensor B39 ¦ Buffer
sensor B4 ¦ Buffer sensor B41 ¦ Flue gas
temp sensor B8 ¦ Segment flow sensor
B10 ¦ Solid fuel boiler sensor B22 ¦ DHW
charging sensor B36 ¦ Buffer sensor B42 ¦
Segment return sensor B73 ¦ Cascade
return sensor B70 ¦ Pool sensor B13 ¦
Solar flow sensor B63 ¦ Solar return
sensor B64 ¦ Primary exch sensor B26
Sensor input BX22 module 1
None ¦ DHW sensor B31 ¦ Collector sensor
B6 ¦ DHW circulation sensor B39 ¦ Buffer
sensor B4 ¦ Buffer sensor B41 ¦ Flue gas
temp sensor B8 ¦ Segment flow sensor
B10 ¦ Solid fuel boiler sensor B22 ¦ DHW
charging sensor B36 ¦ Buffer sensor B42 ¦
Segment return sensor B73 ¦ Cascade
return sensor B70 ¦ Pool sensor B13 ¦
Solar flow sensor B63 ¦ Solar return
sensor B64 ¦ Primary exch sensor B26
None
6042 Sensor input BX21 module 2
None ¦ DHW sensor B31 ¦ Collector sensor B6 ¦
DHW circulation sensor B39 ¦ Buffer sensor B4 ¦
Buffer sensor B41 ¦ Flue gas temp sensor B8 ¦
Common flow sensor B10 ¦ Solid fuel boiler sensor
B22 ¦ DHW charging sensor B36 ¦ Buffer sensor
Sensor BX21 module 2
None ¦ DHW sensor B31 ¦ Collector sensor
B6 ¦ DHW circulation sensor B39 ¦ Buffer
sensor B4 ¦ Buffer sensor B41 ¦ Flue gas
temp sensor B8 ¦ Segment flow sensor
B10 ¦ Solid fuel boiler sensor B22 ¦ DHW
Sensor input BX21 module 2
None ¦ DHW sensor B31 ¦ Collector sensor
B6 ¦ DHW circulation sensor B39 ¦ Buffer
sensor B4 ¦ Buffer sensor B41 ¦ Flue gas
temp sensor B8 ¦ Segment flow sensor
B10 ¦ Solid fuel boiler sensor B22 ¦ DHW
None
