Assigning parameters for the HMI device in STEP 7
6.3 KP8 and KP8F
KP8, KP8F, KP32F
78 Operating Instructions, 11/2011, A5E03284305-02
Procedure
1. Double click in the properties window on slot 2.
The "Properties – F-DI" dialog box opens.
2. Open the "Addresses" tab.
In the "Inputs" and "Outputs" groups, the start values of the address areas are set
depending on the controller used. The signals of the F channels of the HMI device are
mapped in these address ranges.
Parameter Meaning
Inputs > Start Start of address range in which the safety-relevant usage data of
the HMI device are mapped.
Inputs > Process Image Process image to which the address range belongs.
This parameter cannot be entered with a controller of the
SIMATIC CPU 300 type.
Outputs > Start Start of address range in which the safety-relevant usage data of
the HMI device are mapped.
Outputs > Process Image Process image to which the address range belongs.
This parameter cannot be entered with a controller of the
SIMATIC CPU 300 type.
3. Check the default entry of the addresses for "Start".
If necessary, change the address range.
4. Select the "Parameters" tab.
5. Open the "Parameters > Device-specific Panels > Evaluation of the sensors" directory.
6. In the list, select:
– Not activated
"Not activated" is the default entry.
– 1oo2 (2v2)-evaluation, EMERGENCY STOP
– 1oo1 (1v1)-evaluation, single-channel
The selection is based on the connection corresponding with section "General
(Page 55)".
Note
Make sure that the sensor is monitored corresponding with its connection.
7. Click "OK".
The entries are saved. The dialog box closes.
