Connecting
7.3 Connecting components
SIMATIC MV420 / SIMATIC MV440
122 Operating Instructions, 04/2013, A5E02371045-06
Cable sockets
Note
Only the SIMATIC MV440 reader has an ASM socket.
Note
Power supply via for SIMATIC MV440 Ethernet also via Power over Ethernet
The power for the SIMATIC MV440 readers can also be supplied using Power over Ethernet
(PoE), for example when using PoE switches such as:
• SCALANCE X108POE
• SCALANCE X308-2M POE
• SCALANCE XR324-12M POE
• SCALANCE XR324-4M POE
Note
PoE functionality not available for older devices
PoE functionality is not available for older devices with the following order numbers:
• 6GF3440-0CD10
• 6GF3440-0GE10
• 6GF3440-0CD11
• 6GF3440-0GE11
• 6GF3440-0CD21
