Alarm, fault and system messages
11.2 Reporting diagnostics information
SIMATIC MV420 / SIMATIC MV440
342 Operating Instructions, 04/2013, A5E02371045-06
11.2.4 Read and verification error messages
If there is a read error or verification error, the following error codes or English message
strings are output. For further information, please refer to "Overall results" in the online help.
Note
The causes of error 4700 to 4722 are also output in the verification report if there is a
verification error
All verification grades are output in the report as "E". The verification values correspond to
the error code.
Note
Evaluating verification errors as read errors
If the "Evaluate quality 'Poor' as 'N_OK'" check box has been selected in the decoding
settings, a verification error will also be evaluated as 'N_OK'.
Error code
(%c)
Message (%s) Description
0001 No 1D/2D code found in step n No code found in step #n.
0002 Cycletime too short The processing was not completed within the cycle
time limit.
0003 Trigger too fast The processing was interrupted by a trigger signal.
0004 Non ECC200 Code in step n Data matrix code found in step #n that does not
comply with ECC200.
Note
The check for ECC200 is performed only in
adjustment mode and during "Save program".
0005 Step n: Structured Append DMC not supported A DMC type "Structured Append" was found in step n.
This DMC type is not supported.
0006 Step n: Reader Programming DMC not supported A DMC type "Reader Programming Code" was found
in step #n. This DMC type is not supported.
0007 Step n: QR ECI encoding not supported A QR code with "ECI encoding" was found in step #n.
This QR type is not supported.
0008 Step n: QR Byte encoding not supported A QR code with "Byte encoding" was found in step #n.
This QR type is not supported.
0009 Step n: QR Kanji encoding not supported A QR code with "Kanji encoding" was found in
step #n. This QR type is not supported.
0010 Step n: Structured Append QR code not
supported
A QR type "Structured Append" was found in step #n.
This QR type is not supported.
0011 Step n: QR FNC1 encoding not supported A QR code with "FNC1 encoding" was found in
step #n. This QR type is not supported.
0012 Quality is poor in step n A code with the quality evaluation "Poor" was read in
verification mode in step #n.
0013 Nothing found "Scan" or "Autotrigger edge triggered" mode: All
image acquisitions were decoded without result.
