Image processing
4.2 Code verification
SIMATIC MV420 / SIMATIC MV440
70 Operating Instructions, 04/2013, A5E02371045-06
4.2.8.3 Standard report for ISO/IEC 15415
Field name (TAG) Value
Verification type (Qt) 2
If the exposure settings do not comply with the
standard: C
Evaluation (Qs) 3 (Good), 2 (Fair) or 1 (Poor)
Overall grade (Q0) 4, 3, 2, 1 or 0
Reference decode grade (Q7) 4, 3, 2, 1 or 0
Contrast grade (Q1) 4, 3, 2, 1 or 0
Contrast (q1) 0 ... 100
Axial non-uniformity grade (Q2) 4, 3, 2, 1 or 0
Axial non-uniformity (q2) 0.00 ... 1.00
Grid non-uniformity grade (Q3) 4, 3, 2, 1 or 0
Grid non-uniformity (q3) 0.00 ... 1.00
Unused error correction grade (Q4) 4, 3, 2, 1 or 0
Unused error correction (q4) 0.00 ... 1.00
Fixed pattern damage grade (Q5) 4, 3, 2, 1 or 0
Modulation grade (Q6) 4, 3, 2, 1 or 0
Print growth X (q9) -100 ... 100
Print growth Y (q9) -100 ... 100
Cell size (q10) 0 ... 99.9 mil
Aperture (q12) 0, 4 ... 20 mil (0 corresponds to automatic)
ECCLevel (q14) 200
Height (q15) 0 ... 9.99 inches
Width (q16) 0 ... 9.99 inches
Angle (q17) 0 ... 360°
