Operator control and monitoring
9.2 Working with the user interface
SIMATIC MV420 / SIMATIC MV440
178 Operating Instructions, 04/2013, A5E02371045-06
9.2.5.1 Graphical user interface elements
Figure 9-12 Programs
The screenshot shows the interface and interface elements.
Table 9- 6 Programs and template
Template for creating programs
Table 9- 7 Steps
Image acquisition step
Decoder step (variable number)
Character recognition step (OCR, variable number)
Result step (fixed)
