Image processing
4.2 Code verification
SIMATIC MV420 / SIMATIC MV440
48 Operating Instructions, 04/2013, A5E02371045-06
4.2.3.4 Verification standards supported
Note
"Veri-Genius" only available for SIMATIC MV440 readers
This option is available only for the SIMATIC MV440 readers.
For productive use, you require a Veri license (order number 6GF3400-0SL02).
● The readers without a verification license support the following:
– Verification to ISO/IEC 16022:2000, previously the AIM specification
● The readers with a "Veri-Genius" license also support the following standards:
– Data matrix verification to ISO/IEC 15415:2004
– Data matrix verification to AS9132 Rev A:2005 (previously IAQG) for dot peen
marking
– Siemens DPM
– Data matrix verification to AIM DPM-1-2006
– Barcode verification to ISO/IEC 15416:2000 (previously ANSI X3.182-1990)
Note
Uncalibrated verification
If you select the uncalibrated verification reference, data matrix codes will be
evaluated according to ISO 16022 and barcodes according to ISO/IEC 15416. The
evaluation is, however, made without any basic calibration. The standard report
corresponds to the "Standard Report for ISO/IEC 16022" (Page 69) for data matrix
cod
es or the "Standard Report for ISO/IEC 15416" (P
age 73) for verifiable barcodes.
Note
Verification with the "ID-Genius" decoder
If you select the "ID-Genius" decoder (Standard report for the "ID-Genius" decoder
(Page 72)), only uncalibrated verificat
ion is possible. To maximize the read rate of
difficult codes, the evaluation of the code quality is performed in a similar way to
ISO/IEC 16022:2000 however with a different implementation. The calculated quality
values are therefore to some extent not directly comparable with verification to
ISO/IEC 16022:2000.
