Siemens SIMATIC MV440 - Standard Report for AS9132, Rev a

Image processing
4.2 Code verification
SIMATIC MV420 / SIMATIC MV440
Operating Instructions, 04/2013, A5E02371045-06
71
4.2.8.4 Standard report for AS9132, Rev A
Field name (TAG) Value
Verification type (Qt) 3
If the exposure settings do not comply with the
standard: D
Evaluation (Qs) 3 (Good), 2 (Fair) or 1 (Poor)
Overall grade (Q0) 4, 3, 2, 1 or 0
Module size offset grade (Q20) 4, 3 or 0
Module size offset 1 (q20) 0 ... 99.9
Module size offset 2 (q20) 0 ... 99.9
Module center offset grade (Q19) 4, 3 or 0
Module center offset 1 (q19) 0 ... 99.9
Module center offset 2 (q19) 0 ... 99.9
Angle of distortion grade (Q22) 4, 3 or 0
Angle of distortion (q22) -45 ... 45
Ovality grade (Q23) 4, 3 or 0
Ovality (q23) 0.00 ... 99.9
Module fill X (q9) 0 ... 200
Module fill Y (q9) 0 ... 200
Contrast (q1) 0 ... 100
Nominal module size (q10) 0 ... 99.9 mil
ECCLevel (q14) 200
Height (q15) 0 ... 9.99 inches
Width (q16) 0 ... 9.99 inches
Angle (q17) 0 ... 360°
