4.2 Code verification
SIMATIC MV420 / SIMATIC MV440
Operating Instructions, 04/2013, A5E02371045-06
69
4.2.8.2 Standard report for ISO/IEC 16022
Field name (TAG) Value
Verification type (Qt) 4
If the exposure settings do not comply with the
standard: E
Evaluation (Qs) 3 (Good), 2 (Fair) or 1 (Poor)
Overall grade (Q0) 4, 3, 2, 1 or 0
Contrast grade (Q1) 4, 3, 2, 1 or 0
Contrast (q1) 0 ... 100
Axial non-uniformity grade (Q2) 4, 3, 2, 1 or 0
Axial non-uniformity (q2) 0.00 ... 1.00
Print growth grade (Q9) 4, 3, 2, 1 or 0
Print growth X (q9) -100 ... 100
Print growth Y (q9) -100 ... 100
Unused error correction grade (Q4) 4, 3, 2, 1 or 0
Unused error correction (q4) 0.00 ... 1.00
Cell size (q10) 0 ... 99.9 mil
ECCLevel (q14) 200
Height (q15) 0 ... 9.99 inches
Width (q16) 0 ... 9.99 inches
Angle (q17) 0 ... 360°
