Components of the product/spares/accessories
15.2 Accessories
SIMATIC MV420 / SIMATIC MV440
392 Operating Instructions, 04/2013, A5E02371045-06
15.2.3.7 PoE switch
Note
PoE functionality not available for older devices
PoE functionality is not available for older devices with order numbers:
• 6GF3440-0CD10
• 6GF3440-0GE10
• 6GF3440-0CD11
• 6GF3440-0GE11
• 6GF3440-0CD21
The following "PoE switches" are suitable for supplying power to the SIMATIC MV440
readers via the Ethernet cable.
Order number PoE switch Note
6GK5108-0PA00-2AA3 SCALANCE X108POE
6GK5308-2QG00-2AA2 SCALANCE X308-2M POE
6GK5324-4QG00-1AR2
6GK5324-4QG00-1HR2
SCALANCE XR324-12M POE
6GK5324-4QG00-3AR2
6GK5324-4QG00-3HR2
SCALANCE XR324-4M POE
Suitable for SIMATIC MV440
readers with a PoE connector:
• 6GF3440-1CD10
• 6GF3440-1GE10
• 6GF3440-1LE10
15.2.3.8 Cables
SIMATIC MV440 readers are fitted with three M12 plugs / M16 sockets. The connectors
have the following functions:
● M12 – Ethernet cable M12/RJ-45
● M12 – ASM cable
● M16 - Power IO RS-232 cable
● M16 - Power I/O cable
Note
Ordering information
• Either one or all three cables are required depending on the application. The cables
are not part of a complete package and must always be ordered separately.
• There is more than one version of each cable type. In this case, you simply need to
order one version per reader.
