Siemens SIMATIC MV440 - Simatic Mv440; Fittings for Mounting; Reader Lens

Components of the product/spares/accessories
15.2 Accessories
SIMATIC MV420 / SIMATIC MV440
380 Operating Instructions, 04/2013, A5E02371045-06
15.2.3 SIMATIC MV440
15.2.3.1 Fittings for mounting
Order number Fittings for mounting Note
6GF3440-8CA Mounting plate for reader,
SIMATIC MV440
W x H x D (in mm): 80 x 80 x 60,
thickness of the plate: 4 mm
Flexible use for metric and imperial
threads.
15.2.3.2 Reader lens
Reader lenses supported
Order number Reader lenses Comment
6GF9001-1BE01 Mini lens 8.5 mm,
1:1.5 PENTAX C815B(TH)
• Fixed focal distance
• Aperture and focus adjustable
• D = 42 mm, L = 47 mm
6GF9001-1BL01 Mini lens 12 mm,
1:1.4 PENTAX H1214-M(KP)
• Fixed focal distance
• Aperture and focus adjustable
• D = 29.5 mm, L = 35.7 mm
6GF9001-1BF01 Mini lens 16 mm,
1:1.4 PENTAX C1614-M(KP)
• Fixed focal distance
• Aperture and focus adjustable
• D = 29.5 mm, L = 37.2 mm
6GF9001-1BG01 Mini lens 25 mm,
1:1.4 PENTAX C2514-M(KP)
• Fixed focal distance
• Aperture and focus adjustable
• D = 29.5 mm, L = 38.9 mm
6GF9001-1BH01 Mini lens 35 mm,
1:1.6 PENTAX C3516-M(KP)
• Fixed focal distance
• Aperture and focus adjustable
• D = 29.5 mm, L = 41.4 mm
6GF9001-1BJ01 Mini lens 50 mm,
1:2.8 PENTAX C5028-M(KP)
• Fixed focal distance
• Aperture and focus adjustable
• D = 29.5 mm, L = 38 mm
6GF9001-1BK01 Tele lens 75 mm,
1:2.8 PENTAX C7528-M(KP)
• Fixed focal distance
• Aperture and focus adjustable
• D = 34 mm, L = 63.6 mm
