Components of the product/spares/accessories
15.2 Accessories
SIMATIC MV420 / SIMATIC MV440
Operating Instructions, 04/2013, A5E02371045-06
381
Finding the suitable lens and the size of the viewing window
Note
Configuration: necessary for finding the suitable lens
The configuration is used to find the suitable lens.
• Use the configuration table.
You require the configuration table to find out which lens is suitable for SR, HR and UR
readers.
Table 15- 1 Configuration table
Configura
tion
Requirements Components Order number Comment
Built-in ring light red 6GF3440-8DA11
Built-in white ring light 6GF3440-8DA21
Built-in green ring light 6GF3440-8DA31
Protective lens cover
∅65 metal/glass
6GF3440-8AC11
Protective lens cover
∅65 metal/PMMA
6GF3440-8AC21
I Near field
(from 7 to 80 cm)
Protective lens cover
∅65 PC/PC
6GF3440-8AC12
Compact variant, minimal cabling
work required.
PC = Polycarbonate
PMMA = Polymethyl
methacrylate
External ring lamp
Red light, clear
6GF9004-8DA01
External ring lamp
IR light, clear
6GF9004-7BA01
Protective lens cover
∅50 metal/glass
6GF9002-7AA
E Far field
(from 0.5 to 3 m)
Protective lens cover
∅50 metal/PMMA
6GF9002-7AA01
Accessories for operating the
external lamps:
• 16.5 V power supply unit
6GF9002-8PS
• External ring light holder
6GF3440-8CD
• Connecting cable for the
lamp, 10 m,
3RX8000-0CC42-1AL0
Protective lens cover
∅65 metal/glass
6GF3440-8AC11 Lens cover ∅ 65,
without internal lamp
Protective lens cover
∅65 metal/PMMA
6GF3440-8AC21
Protects wide lenses
Protective lens cover
∅50 metal/glass
6GF9002-7AA
T
Lens cover ∅ 50
without internal lamp
Protective lens cover
∅50 metal/PMMA
6GF9002-7AA01
Protects long lenses
