Components of the product/spares/accessories
15.2 Accessories
SIMATIC MV420 / SIMATIC MV440
Operating Instructions, 04/2013, A5E02371045-06
377
15.2.2.4 Built-in ring light
Note
SIMATIC MV420 SR-B/P
In the SIMATIC MV420 SR-B/P (6GF3420-0AA20, 6GF3420-0AA40), the integrated red
MV420 ring light (6GF3420-0AC00-1LT0) is already fitted.
Order number Ring light Note
6GF3420-0AC00-1LT0 Built-in MV420 red ring light for SIMATIC MV420
Light source: Red/amber LED (618 nm)
Fittings supplied
6GF3420-0AC00-2LT0 Built-in MV420 white ring light for SIMATIC MV420
Light source: LED white (425 to 610 nm)
Fittings supplied
6GF3420-0AC00-3LT0 Built-in MV420 IR ring light for SIMATIC MV420
Light source: Infrared LED (888 nm)
Fittings supplied
15.2.2.5 Cables
The SIMATIC MV420 reader is fitted with an industrial M12 plug and an M16 socket. The
connectors have the following functions:
● M12 – Ethernet cable M12/RJ-45
● M16 - Power IO RS-232 cable (plus ASM)
Note
Ordering information
• Either one or two cables are required depending on the application. The cables are
not part of a complete package and must always be ordered separately.
• There is more than one version of each cable type. In this case, you simply need to
order one version per reader.
M12 – Ethernet cable M12/RJ-45
This cable connects the reader with a communications partner over Ethernet.
Due to its short length, the following cable is intended only for commissioning and service:
Order number Ethernet cable Note
6XV1871-5TH20 Ethernet cable M12/RJ45 2 m
• Fitted with M12 plug, 8-pin
and RJ-45 plug
• Length: 2 m
Suitable for all SIMATIC MV400
readers.
Other 6XV1871-5... cables can
be found in the new catalog,
ID10 ● 2013 and the Industry
Mall.
