3.4 Design of the SIMATIC MV440
SIMATIC MV420 / SIMATIC MV440
Operating Instructions, 04/2013, A5E02371045-06
21
3.4 Design of the SIMATIC MV440
The image below shows the SIMATIC MV440 reader.
① LED display for operating mode ⑤ ASM female connector
② Protective lens cover ∅ 65 ⑥ Combined cable socket for the power
supply, I/O connectors and RS-232
③ Nameplate ⑦ Housing SIMATIC MV440
④ Ethernet socket (PoE) ⑧ Internal lamp
Figure 3-2 Design of the SIMATIC MV440
