Description
3.5 Structure of the nameplate
SIMATIC MV420 / SIMATIC MV440
22 Operating Instructions, 04/2013, A5E02371045-06
3.5 Structure of the nameplate
The nameplate of the reader with the order number is located on the housing and shows the
order number and other important product information.
s
SIMATIC MV440 XX
DC 24V 270mA
PoE 48V 135mA
NEC Class 2
Made in Germany
SIMATIC MV440 XX
6GF3440-ABCDE
SVPJM123456
Siemens AG, Industry Sector
MAC-ADRESSE
Ta: 0°C...50°C
X
IP67
Nameplate right Nameplate left
① Manufacturer ⑦ Data matrix code
② Product designation ⑧ Product designation with order number
and manufacturer code/serial number
③ Warning symbol ⑨ IP rating
④ C-Tick mark ⑩ MAC address, 12-character
⑤ CE mark ⑪ Product version of the device
⑥ KC symbol
Figure 3-3 Example of the SIMATIC MV440 nameplate
Note
A second MAC address is also reserved when the device supplied. This MAC address is the
MAC address on the nameplate + 1.
