Technical data
13.2 Technical specifications of the reader
SIMATIC MV420 / SIMATIC MV440
356 Operating Instructions, 04/2013, A5E02371045-06
13.2 Technical specifications of the reader
SIMATIC MV440
Reader
Image acquisition
• CCD chip 1/3", 640 x 480, square pixels; full-frame shutter
• CCD chip 1/3", 1024 x 768, square pixels; full-frame
shutter
• CCD chip 1/1.8", 1600 x 1200, square pixels; full-frame
shutter
Image data transfer Triggered and automatic image acquisition
Casing Die-cast aluminum
Dimensions (W x H x D) in mm 65 × 122 × 55
Weight
• Approx. 0.45 kg (without protective lens cover)
• Approx. 0.55 kg (without protective lens cover)
Degree of protection IP 67 to IEC 60529
Supply voltage, current consumption
• Type of supply voltage
DC
• Supply voltage from:
– M16 Power/IO connector
– M12 ASM connector
24 V DC ±20 %
• Supply voltage from:
– Power over Ethernet
according to IEEE802.3af
(PoE), however only phantom
power
48 V DC, (min. 36 V DC, max: 57 V DC)
• Current consumption (without I/O
signals)
• 24 V DC: Maximum 270 mA
• PoE: Maximum 135 mA
• Making current (at 24 V DC)
I
1
max. 2 A; < 1 ms
• Power down bridging time
(at 24 V DC)
10 ms
Power over Ethernet (PoE)
• Powered Device (PD)
Type 1, class 2 (6.49 W)
• Type of supply
Phantom power (IEEE 802.af)
