Siemens SIMATIC MV440 - External lighting units

Components of the product/spares/accessories
15.2 Accessories
SIMATIC MV420 / SIMATIC MV440
Operating Instructions, 04/2013, A5E02371045-06
371
15.2.1.2 External lighting units
Note
See the dimension drawings in the image database for dimensions
You will find the exact dimensions in the dimension drawings in the Image Database
(http://www.automation.siemens.com/bilddb/
) of Siemens AG.
Lighting units for external lighting
Order number External lamps Note
6GF9004-7BA01 LED ring light metal IR clear
• Light source: 850 nm
• Lighting distance: 500 mm … 3000 mm
• For SIMATIC VS100
• Protective lens cover - suitable dimensions
(W x H x D): 116 x 116 x 42 mm
• Degree of protection IP67D
Short support brackets are
supplied.
6GF9004-8DA01 LED ring light metal red clear
• Lighting distance: 500 mm … 3000 mm
• For SIMATIC VS100
• Protective lens cover - suitable dimensions
(W x H x D): 116 x 116 x 42 mm
• Degree of protection IP67
Short support brackets are
supplied.
6GF3440-8CD SIMATIC MV440 ring light holders for
SIMATIC VS100 ring lamps
order number:
• 6GF9004-7BA01
• 6GF9004-8DA01
• Dimensions (W x H x D):
175 x 225 x 3 mm
Screws are supplied.
Power supply unit
Siemens recommends using the power supply unit to operate the external lighting unit:
Order number Rail-mounted power supply unit Note
6GF9002-8PS SIMATIC VS100 DIN rail-mounted power
supply unit for SIMATIC VS100 ring lamps
order number:
• 6GF9004-7BA01
• 6GF9004-8DA01
• Input voltage: 110 to 230 V AC
• Output voltage: 16.5 V DC
Recommended cable 10 m long.
Order number:
3RX8000-0CC42-1AL0
