Components of the product/spares/accessories
15.2 Accessories
SIMATIC MV420 / SIMATIC MV440
Operating Instructions, 04/2013, A5E02371045-06
379
M16 – ASM cable
This cable is for connection to ASM devices such as RFC180C and ASM456. Power can
also be supplied via this cable allowing the reader to be operated with only one cable. This
cable is suitable only for the SIMATIC MV420.
Order number Cables and connectors Note
6GF3420-0AC00-2CB0 2 m Suitable for readers:
• 6GF3420-0AA20
• 6GF3420-0AA40
• 6GF3420-0AX20
• 6GF3420-0AX40
M16 power cable / power I/O cable / power I/O RS232 cable
These cables are used for the camera voltage supply. The power I/O RS232 cable also has
wires for connecting digital inputs/outputs and the RS-232 serial interface.
Order number Cables Note
6GF3400-0BH15 1.5 m MV400 push-pull power
cable
• M16 with connector prefitted
at one end
• Prefitted push-pull
• For power supply only, no
I/O, no RS 232
• Length: 1.5 m
Suitable for all SIMATIC MV400
readers
6GF3400-1BH20 2 m MV400 push-pull power
cable
• M16 with connector prefitted
at one end
• Open end
• Push-pull connectors
supplied
• For power supply only, no
I/O, no RS232
• Length: 2 m
Suitable for all SIMATIC MV400
readers
6GF3440-8BA2 SIMATIC MV440/
SIMATIC MV420 power IO RS-
232 cable
• M16 with connector prefitted
at one end
• Open end
• Length: 10 m
• Lines for I/O and RS232
Suitable for all SIMATIC MV400
readers
