Operator control and monitoring
9.2 Working with the user interface
SIMATIC MV420 / SIMATIC MV440
Operating Instructions, 04/2013, A5E02371045-06
159
Online help
Note
Access to online help with the "?" button or CD
Each screen of the adjustment support has a "?" button at the top right with which you can
open the online help at any time. The online help opens with the context-sensitive help text
relating to your current task.
The online help is also saved on the CD so it can be used offline.
The user interface of the reader is based on a Web server and has the following dialog
boxes for image evaluation:
Tasks
In the left part of the user interface, you will find a selection of tasks in the form of buttons.
You can start the required task by clicking the appropriate button. The dialog for this task
then opens on the right side of the user interface. At the same time, the text of the buttons
changes to bold and the font color becomes white.
You can select the following tasks:
● Adjustment - Set image
● Adjustment - Save program
● Connections - Specify interfaces and plant integration
● Programs - Specify processing task
● Process - Select and start program
● Options - Make general device settings
● Information - Access device, statistical and diagnostic information
● Maintain - Save/restore settings, run firmware updates and enter the VeriCode® license
● Stop - Stop processing mode
