Operator control and monitoring
9.2 Working with the user interface
SIMATIC MV420 / SIMATIC MV440
216 Operating Instructions, 04/2013, A5E02371045-06
Data records
The "Data records" group box shows you the number of diagnostics events currently in the
event buffer.
In "Content", you can use the check boxes to select the information you want to display
about the diagnostics events in the buffer:
Error Information on the occurrence and acknowledgment (manual or automatic) of
errors
Results Evaluation results
Image Information on the image acquisition, for example exposure time, brightness
States Mode change (change to RUN, ADJUST, Self-test, etc.)
Control Changing control of the reader
Diagnostics Changes that affect diagnostics, for example, changing the diagnostics options
or fetching a time stamp from an SNTP server
● If you click the "Save as CSV" button, a dialog opens in which you can store the events
currently selected under "Content" as a CSV file.
● Clicking the "Open & save" button opens a Web page with all the events of the events
buffer. You can save this Web page on your computer in various formats.
Persistent data records
Note
Activating persistent data records
The persistent data records option is activated, when necessary, in the "Diag.&monitoring"
tab under Options.
● Clicking the "Reset" button deletes all the entries in the event buffer including the entries
relating to temporary PROFINET I/O errors.
● Clicking the "Open & save" button opens a Web page with all the diagnostics entries
saved permanently on the reader. You can save this Web page on your computer.
● If you click the "Save as CSV" button, a dialog opens in which you can save the
diagnostics events permanently stored on the reader as a CSV file.
Note
Detailed description of parameters in the online help
For a detailed description of the parameters and possible values, refer to the online help.
