16 Configuration Console Tool

216

Commissioning PC Stations - Manual and Quick Start

Release 5/2005

C79000-G8976-C156-07

Activity

3 Double-click on a protocol, for example, on “S7” for the trace settings of SAPI S7. The

corresponding Properties dialog box opens.

4 Activate the trace by setting the first option box to “Overwrite trace file” or “Append to trace file”.

5 “Apply” the settings.
