18 DCOM Settings with the dcomcnfg System Program

272

Commissioning PC Stations - Manual and Quick Start

Release 5/2005

C79000-G8976-C156-07

Specifying Configuration Permissions

Activity

1. After clicking the “Edit” button in the “Use custom configuration permissions” box, the following

dialog box appears:

2. Add the account of the user under which the OPC Server will be started and, if different, the

account under which the client runs.
