7 Example — OPC Application for Industrial Ethernet
92
Commissioning PC Stations - Manual and Quick Start
Release 5/2005
C79000-G8976-C156-07
Activity
4.
Select the following OPC items from the appropriate branches in the middle window and
transfer these variables to the right-hand pane by clicking on the arrow button.
Examples:
SIMATIC_400(1)_CPU_416-1.Pump2.Current
SIMATIC_400(1)_CPU_416-1.Pump2.Emergency
SIMATIC_400(1)_CPU_416-1.Pump2.Flow
SIMATIC_400(1)_CPU_416-1.Pump2.Power
The items are added to the group after you confirm the dialog with “OK”.
