Configuration options
SIMATIC PCS 7 BOX
RTX
SIMATIC PCS 7 BOX
with PCS 7
AS mEC RTX or with
PCS 7 AS RTX
SIMATIC PCS 7 BOX
with AS 41x
SIMATIC PCS 7 BOX
with AS 41xH
ES/OS single station
with up to 2000 OS PO
possible possible possible possible
OS single station with
up to 2000 OS PO
possible possible possible possible
SIMATIC PDM possible possible possible possible
SIMATIC PCS 7 Main‐
tenance Station
possible possible possible possible
SIMATIC BATCH up to
10 units
possible possible possible
Web server, based on
Windows 7 for up to 2
Web clients
possible possible possible
High-precision time
stamps
possible possible
S7 F systems possible
(can be ordered as
AS 400F)
SIMATIC Safety Matrix possible
Note
The SIMATIC PCS 7 BOX PC with integrated AS (SIMATIC PCS 7 BOX RTX) is described in
greater detail in this documentation.
Location of use
The SIMATIC PCS 7 BOX can be placed on-site where the automation process takes place,
because it is designed for these environmental conditions.
Required basic knowledge
This documentation is intended for personnel involved in configuring, commissioning, and
servicing.
Basic knowledge of the general use of the PC/programming device and of the use of the
Windows operating system is required. In addition to this, you should be familiar with the
functions and configurations of SIMATIC S7 (S7-400, STEP 7), SIMATIC NET and SIMATIC
PCS 7.
