Procedure
Note
A user program running in the CPU is stopped with the following procedure.
1. If the CPU is in the RUN operating mode, select the menu command CPU > STOP.
The user program running on the CPU is stopped.
2. Select the menu command CPU > Close Controller.
This menu command is only available when the user program of the WinLC RTX software
PLC (controller) is in the "started" operating mode.
3. Select the menu command CPU > Register Controller for Start with PC Startup.
This menu command is only available when the "Autostart CPU" function is not activated.
If the CPU > Register Controller for Start with PC Startup menu command is not available,
the controller is already registered for starting with the PC startup.
4. Select the menu command CPU > Start Controller.
The "ON" light is green in the PS area of the "WinLC RTX" dialog box.
5. Select the menu command CPU > Tools > Options.
The "Options" dialog box opens.
6. Open the "Autostart" tab.
7. Activate the "Autostart CPU" check box.
8. Click "OK" to apply the settings.
The "Options" dialog box opens.
9. Select the menu command CPU > RUN.
The "Startup Type" dialog box opens.
10.Activate the "Restart" check box and click "OK".
The RUN operating mode is activated.
9.15 How to compile and download the AS
Introduction
You download the user program of the SIMATIC PCS 7 AS mEC RTX automation system in
the same way as an S7-400 using the engineering station.
Requirements
● Automation License Manager is installed on the engineering station and the SIMATIC PCS
7 AS mEC RTX.
● SIMATIC Manager is open and your PCS 7 project is displayed in the Component view.
Commissioning and configuring SIMATIC PCS 7 AS mEC RTX
9.15 How to compile and download the AS
BOX (V8.1)
114 Function Manual, 03/2015, A5E32711362-AC
