7. Click "Properties".
The "WinLC properties" dialog box opens.
– Select the entry "CP5611" in the "Available Adapters" list. Drag and drop the CP to the
index IF1.
– Click the "Confirm and restart the CPU" button. The settings are applied and the
controller are restarted.
– Click "OK".
The "WinLC properties" dialog box closes.
8. Click "OK".
The "Edit Component" dialog box closes.
9. Check the configurations in HW Config and in the Station Configuration Editor to ensure
they match. The recommended configuration is shown in section " Requirements for loading
the BOX PC (Page 46) ".
Note
Ensure that the names of the PC station match in HW Config and in the configuration in
the Station Configuration Editor of the SIMATIC PCS 7 BOX RTX.
10.Click "OK".
The Station Configuration Editor closes.
11.Select the menu command CPU > RUN.
The "Startup Type" dialog box opens.
12.Activate the "Restart" check box and click "OK".
The RUN operating mode is activated.
13.Download the PC station via NetPro.
7.5.9 How to download the BOX PC
Requirements
● You have created the PCS 7 project.
● The following components are installed on the BOX PC:
– Operating system
– PCS 7
– Software package WinAC RTX
● The settings on the BOX PC are completed in the Station Configuration Editor (see section
" Requirements for loading the BOX PC (Page 46) ".
Commissioning and configuration of SIMATIC PCS 7 BOX RTX
7.5 Configuring SIMATIC PCS 7 BOX RTX in the PCS 7 network
BOX (V8.1)
Function Manual, 03/2015, A5E32711362-AC 81
