Switching the logs on the bus (Industrial Ethernet)
Note
Never disable the TCP/IP or ISO protocol during operation since they are both needed for the
configured operation!
If you want to change a bus in a system to a different protocol (from TCP/IP protocol to ISO
protocol, for example), temporarily set a mixed protocol (TCP/IP protocol and ISO protocol)
on the engineering station. Then, download the configuration data to all affected systems (for
example, the AS and engineering station).
7.3.8 How to open the operator panel of the CPU
Introduction
The CPU does not have any display or operator control elements. This is why an operator
panel is displayed on the computer screen after the CPU starts. This operator panel shows all
displays and operator control elements exactly as they appear for a CPU in an AS. You
manipulate the operator control elements on the computer screen with the mouse.
Before downloading the project data to the CPU, check the operating mode of the CPU. You
can only download the project data to the CPU when it is in STOP mode.
Requirements
The following software is installed on the SIMATIC PCS 7 BOX RTX:
● Operating system
● PCS 7
● Software package WinAC RTX
Note
Startup
The PCS 7 applications cannot be operated until the "Station Configuration Editor" has
been run (for example, the WinLC RTX operator panel).
Procedure
Select the menu command Start > SIMATIC > PC Based Control > WinAC RTX.
The operator panel with the "WinLC RTX" dialog box opens.
You can move the operator panel to the desktop and keep it open.
Commissioning and configuration of SIMATIC PCS 7 BOX RTX
7.3 Configuring SIMATIC PCS 7 BOX RTX for a single-station system
BOX (V8.1)
54 Function Manual, 03/2015, A5E32711362-AC
