Additional information
Manual
SIMATIC; Windows Automation Center RTX; WinAC RTX
7.5 Configuring SIMATIC PCS 7 BOX RTX in the PCS 7 network
7.5.1 Overview of configuration tasks
Introduction
If you integrate the SIMATIC PCS 7 BOX station in an existing PCS 7 system, you connect
the SIMATIC PCS 7 BOX station to the plant bus and terminal bus.
This configuration has the following additional special features:
The time of day on the AS and OS within the SIMATIC PCS 7 BOX station can be
synchronized on the plant bus using a system clock such as SICLOCK TC 400.
The AS in the PCS 7 network can communicate with the CPU within the SIMATIC PCS 7
BOX station.
Requirements
The PC stations (engineering station and SIMATIC PCS 7 BOX) are connected via an
administered Windows network.
The following software is installed on the SIMATIC PCS 7 BOX RTX:
Operating system
PCS 7
Software package WinAC RTX with controller
Overview
The following configuration steps are performed in order to commission SIMATIC PCS 7 BOX
in the PCS 7 network:
Step What?
1 Selecting the network adapter in SIMATIC Shell (Page 73)
2 Expanding the PCS 7 project to include a SIMATIC PCS 7 BOX station (Page 74)
3 Renaming the SIMATIC PC station (Page 75)
4 Editing the hardware configuration of the BOX PC (Page 76)
5 Setting the access point on the BOX PC (Page 77)
6 Configuring NetPro for SIMATIC PCS 7 BOX in the PCS 7 network (Page 78)
7 Configuring the Station Configuration Editor (Page 80)
8 Configuring and downloading the BOX PC (Page 81)
Commissioning and configuration of SIMATIC PCS 7 BOX RTX
7.5 Configuring SIMATIC PCS 7 BOX RTX in the PCS 7 network
BOX (V8.1)
72 Function Manual, 03/2015, A5E32711362-AC
