7.2 Requirements for loading the BOX PC
Consistent configuration
In order to load a BOX PC, the configuration of the components in HW Config and in the Station
Configuration Editor must match.
You can learn about the steps required prior to loading the BOX PC in the sections dealing
with specific configurations.
Name of the BOX PC
Note
Ensure that the name of the PC station matches the name in HW Config and in the configuration
in the Station Configuraton Editor.
Configuration in HW Config and the Station Configuration Editor for SIMATIC PCS 7 BOX RTX
The configuration of the SIMATIC PCS 7 BOX RTX in HW Config and in the Station
Configuration Editor ("Components" tab) is shown in the following table.
HW Config Station Configuration Editor ("Components" tab)
Index Module Index Name Type
1 1
2
IF1
IF2
IF3
IF4
WinLC RTX 2
IF1
IF2
IF3
IF4
WinLC RTX WinLC RTX
3 WinCC application 3 WinCC application WinCC application
4 IE_General
(only when plant bus is used)
4 IE_General
(only when plant bus is used)
IE_General
(only when plant bus is
used)
5 5
Commissioning and configuration of SIMATIC PCS 7 BOX RTX
7.2 Requirements for loading the BOX PC
BOX (V8.1)
46 Function Manual, 03/2015, A5E32711362-AC
