Note
Startup
The PCS 7 applications cannot be operated until the "Station Configuration Editor" has been
run (for example, the WinLC RTX operator panel).
Windows network settings for SIMATIC PCS 7 BOX RTX
The TCP/IP address must be assigned for the SIMATIC PCS 7 BOX RTX in the Windows
network settings and this address must match the one configured in HW Config.
Note
Assigning IP addresses via DHCP
Please ensure that the SIMATIC PCS 7 BOX RTX is always assigned the TCP/IP address
configured in HW Config.
7.3 Configuring SIMATIC PCS 7 BOX RTX for a single-station system
7.3.1 Overview of configuration tasks
Requirements
The following software is installed on the SIMATIC PCS 7 BOX RTX:
● Operating system
● PCS 7
● Software package WinAC RTX
Overview
The following configuration steps are performed in order to commission SIMATIC PCS 7 BOX
RTX for a single-station system:
Step What?
1 Creating a new PCS 7 project (Page 48)
2 Renaming the SIMATIC PC station (Page 49)
3 Editing the hardware configuration of the BOX PC (Page 50)
4 Checking the settings of the PG/PC interface (Page 50)
5 Configuring the Station Configuration Editor (Page 51)
Commissioning and configuration of SIMATIC PCS 7 BOX RTX
7.3 Configuring SIMATIC PCS 7 BOX RTX for a single-station system
BOX (V8.1)
Function Manual, 03/2015, A5E32711362-AC 47
