7.4.9 How to configure the SIMATIC PCS 7 BOX RTX
Requirement
Perform configuration directly on the BOX PC.
The following software is installed on the SIMATIC PCS 7 BOX RTX:
Operating system
PCS 7
Software package WinAC RTX
Setting the components on the SIMATIC PCS 7 BOX RTX
1. When the CPU is in RUN mode, select the CPU > STOP menu command in the operator
panel of the CPU on the SIMATIC PCS 7 BOX RTX .
The user program running on the CPU is stopped.
2. Select the menu command Start > Station Configuration Editor on the SIMATIC PCS 7
BOX RTX .
3. Click "Station name" and enter the name of the PC station.
Note
This name must match the project-specific name of the PC station in the PCS 7 project.
4. Insert the missing components in the Station Configuration Editor. To do this, click "Add...".
The "Add Component" dialog box opens.
5. Select "WinCC application" as the type and set the same index (slot number) that you set
for the WinCC application in HW Config.
6. Select the (WinLC RTX) software PLC and click "Edit".
The "Edit Component" dialog box opens.
7. Click "Properties".
The "WinLC properties" dialog box opens.
Select the entry "CP5611" in the "Available Adapters" list. Drag and drop the CP to the
index IF1.
Click the "Confirm and restart the CPU" button. The settings are applied and the
controller are restarted.
Click "OK".
The "WinLC properties" dialog box closes.
8. Click "OK".
The "Edit Component" dialog box closes.
Commissioning and configuration of SIMATIC PCS 7 BOX RTX
7.4 Configuring SIMATIC PCS 7 BOX RTX with external engineering
BOX (V8.1)
66 Function Manual, 03/2015, A5E32711362-AC
