6. Click "Edit" in the "Settings for Compilation/Download" group.
The "Compile program/download to target system" dialog box opens.
– Select the "Compile Charts as Program" tab, then click "Entire program" in the "Scope"
group.
– Select the "S7 Download" tab, then click "Entire program" in the "Download mode" group.
7. Click "OK" to close the "Compile program/download to target system" dialog box.
8. In the tree view of the SIMATIC PC station of SIMATIC PCS 7 BOX RTX , select the "OS ..."
object and select the check box in the "Compile" column.
Note
The OS does not have to be downloaded since the configuration data are used locally.
9. Click "Edit" in the "Settings for Compilation/Download" group.
The "Settings: Compile OS" dialog box is opened.
– On the "Which areas do you want to assign to which operator stations?" dialog page,
click "Next".
– On the "Select the network connections of the S7 programs belonging to the areas"
dialog page, click "Next".
– The first time you perform a compilation, on the "Select the data you want to compile
and the scope of the compilation" dialog page click "Entire OS" and select the "With
memory reset" check box in the "Scope" group.
– Click "Apply".
The project is analyzed and the "Settings: Download OS" dialog box opens.
10.Click "Start" in the "Compile and Download Objects" dialog box.
11.Click "OK" to close the next dialog boxes displayed.
12.Check and close the log file.
13.Click "Close" to close the "Compile and Download Objects" dialog box.
Additional information
● Online help on the dialog boxes
7.3.10 How to set the CPU in RUN
Introduction
After you have downloaded the AS data and OS data to the CPU, you still have to set the CPU
to RUN mode.
Commissioning and configuration of SIMATIC PCS 7 BOX RTX
7.3 Configuring SIMATIC PCS 7 BOX RTX for a single-station system
BOX (V8.1)
56 Function Manual, 03/2015, A5E32711362-AC
