1. Open the PCS 7 project in SIMATIC Manager.
2. In the component view, select the SIMATIC PC station (SIMATIC PCS 7 BOX) which
contains the CPU.
3. Select the menu command PLC > Download.
The "Download CPU in Current Project" dialog box opens.
4. If the dialog box warns you that the configuration data will be overwritten, make the decision
as follows:
Click "OK" for initial commissioning.
If the PC station is in process mode, you can only click "OK" during an allowed
interruption of the communication.
The "Stop Target Modules" dialog box opens.
5. Click "OK" in the "Stop Target Modules" dialog box to confirm.
The "Download" dialog box opens.
6. Click "OK" to start the download process.
The PC station is read for operation once the configuration is loaded.
Switching the logs on the bus (Industrial Ethernet)
Note
Never disable the TCP/IP or ISO protocol during operation since they are both needed for the
configured operation!
If you want to change a bus in a system to a different protocol (from TCP/IP protocol to ISO
protocol, for example), temporarily set a mixed protocol (TCP/IP protocol and ISO protocol)
on the engineering station. Then, download the configuration data to all affected systems (for
example, the AS and engineering station).
7.4.11 How to open the operator panel of the CPU
Introduction
The CPU does not have any display or operator control elements. This is why an operator
panel is displayed on the computer screen after the CPU starts. This operator panel shows all
displays and operator control elements exactly as they appear for a CPU in an AS. You
manipulate the operator control elements on the computer screen with the mouse.
Before downloading the project data to the CPU, check the operating mode of the CPU. You
can only download the project data to the CPU when it is in STOP mode.
Commissioning and configuration of SIMATIC PCS 7 BOX RTX
7.4 Configuring SIMATIC PCS 7 BOX RTX with external engineering
BOX (V8.1)
68 Function Manual, 03/2015, A5E32711362-AC
