Requirement
The following software is installed on the SIMATIC PCS 7 AS mEC RTX:
● Operating system
● Software package WinAC RTX with controller
● You can access the Windows interface of the SIMATIC PCS 7 AS mEC RTX. Options:
– A Remote Desktop connection has been established via network connection 1 (plant
bus).
– Monitor, mouse and keyboard are connected to the extension module EM PC of the
SIMATIC PCS 7 AS mEC RTX.
Note
Startup
The PCS 7 applications cannot be operated until the "Station Configuration Editor" has
been run (for example, the WinLC RTX operator panel).
Procedure
1. Start the operator panel of the CPU with the menu command Start > SIMATIC > PC Based
Control > WinLC RTX.
The operator panel opens with the "WinLC RTX" dialog box.
You can move the operator panel on the desktop and keep it open.
Example: How to stop the automation program on the CPU
1. Click "STOP" in the operator panel of the CPU.
2. Verify that the virtual signal lamp indicates "STOP" mode.
Additional information
● Manual
SIMATIC; Windows Automation Center RTX; WinAC RTX
9.14 How to activate the automatic start of the AS
Setting the start characteristics
Note
The start characteristics for the SIMATIC PCS 7 AS mEC RTX are factory set.
You can automatically start the CPU after switching on the SIMATIC PCS 7 AS mEC RTX and
set it to RUN operating mode.
Commissioning and configuring SIMATIC PCS 7 AS mEC RTX
9.14 How to activate the automatic start of the AS
BOX (V8.1)
112 Function Manual, 03/2015, A5E32711362-AC
