Requirements
● The objects have been compiled and downloaded.
● The operator panel is open and in the foreground.
Procedure
1. Click "RUN" in the operator panel.
Additional information
● Manual
SIMATIC; Windows Automation Center RTX; WinAC RTX
7.4 Configuring SIMATIC PCS 7 BOX RTX with external engineering
7.4.1 Overview of configuration tasks
Introduction
For the "SIMATIC PCS 7 BOX with external engineering" configuration, the engineering station
and SIMATIC PCS 7 BOX station must be viewed separately during commissioning and
configuration.
Requirements
● The PC stations (engineering station and SIMATIC PCS 7 BOX station) are connected via
an administered Windows network.
● The following software is installed on the SIMATIC PCS 7 BOX RTX:
– Operating system
– PCS 7
– Software package WinAC RTX
Overview
The following configuration steps are performed in order to commission SIMATIC PCS 7 BOX
RTX with external engineering:
Step What?
1 Selecting the network adapter in SIMATIC Shell (Page 58)
2 Creating a new PCS 7 project (Page 59)
3 Renaming the SIMATIC PC station (Page 60)
4 Expanding the PCS 7 project to include the external ES (Page 61)
Commissioning and configuration of SIMATIC PCS 7 BOX RTX
7.4 Configuring SIMATIC PCS 7 BOX RTX with external engineering
BOX (V8.1)
Function Manual, 03/2015, A5E32711362-AC 57
